BEAM P

LUS FOR

E

XISTING

B

UILDINGS

I

NDOOR

E

NVIRONMENTAL

Q

UALITY

(I

EQ

)

V

ERSION

1.2

I

EQ

17

I

NTERIOR

L

IGHTING IN

N

ORMALLY

O

CCUPIED

A

REAS

Copyright © 2012 BEAM Society Limited. All rights reserved.

Page 138

sensors in perimeter zones and/or occupancy sensors.

M

EASURED

P

ERFORMANCE

For lighting installations that are already installed, horizontal and vertical

illuminance and luminance can be measured using a lux meter and a

luminance meter. The colour quality of lamps can be assessed from the

lamp specifications. Colour appearance (correlated colour temperature)

can be checked from the lamp labels or by measurement using a colour

meter. Flicker can be assessed by whether the specified ballasts are

magnetic or electronic, and can be tested using a simple ‘flicker meter’.

C

OMPUTATION

The ‘lumen method’ can be used to calculate the maintained illuminance

over the working plane according to the calculation procedure described

in Section 4.5.3 of the CIBSE Code or in Appendix 3 of the CIBSE

Lighting Guide [6]. The calculated maintained illuminance will then be

checked for compliance with the recommendations given in Section 2.6.4

of the Code, or the recommendations given in Chapter 5 of the Guide.

The illuminance variation consists of ‘uniformity’ which is concerned with

illuminance conditions on the task and immediate surroundings, and

‘diversity’ which expresses changes in illuminance across a larger space.

The uniformity and diversity can be calculated according to that

described in Section 4.5.4 of the Code. The calculated uniformity

(minimum to average illuminance) over any task area and immediate

surround should not be less than 0.8. The diversity of illuminance

expressed as the ratio of the maximum illuminance to the minimum

illuminance at any point in the ‘core area’ of the interior should not

exceed 5:1. The core area is that area of the working plane having a

boundary 0.5 m from the walls.

The glare index can be calculated according to either of the two methods

described by CIE

[2]

, or the CIBSE Technical Memoranda [7]. These

methods are also summarised in Section 4.5.6 of the CIBSE Code

[3]

.

The calculated glare index shall be checked for compliance with the

recommendations given in Section 2.6.4 of the Code or Chapter 5 of the

Lighting Guide.

For assessment using the IESNA Lighting Criteria, the calculation

methods described in Chapter 9 of the IESNA Lighting Handbook can be

used for the calculation of the following parameters:

horizontal and vertical illuminance;

glare: VCP or UGR; and

luminance.

Alternatively, a validated computer program such as RADIANCE,

LIGHTSCAPE etc, can be used for the calculation. The calculated results

will then be checked for compliance with the recommended criteria in the

IESNA Lighting Design Guide.

B

ACKGROUND

Energy efficiency aspects of electric lighting are dealt with in the

assessment of energy use. This section deals with the lighting quality

and maintenance aspects of lighting. Lighting quality is a complicated

subject and is an integration of task performance, visual comfort, social

communication, mood, health, safety and well-being and aesthetic

judgment. It is also related to economics and the environment in respect

of the installation, maintenance and operation of the lighting system.

Proper lighting maintenance (clean lamps and luminaires, lamps

replaced periodically to avoid depreciation) is important to maintain good

6

The Chartered Institution of Building Services Engineers. Lighting Guide LG7: Lighting for offices. London, CIBSE, 1993.

7

The Chartered Institution of Building Services Engineers. Technical Memoranda TM10. Calculation of glare indices.

London, CIBSE, 1985.
