BEAM P

LUS FOR

E

XISTING

B

UILDINGS

E

NERGY

U

SE

(E

U

)

V

ERSION

1.2

E

U

9 M

ETERING AND

M

ONITORING

Copyright © 2012 BEAM Society Limited. All rights reserved.

Page 84

4

E

NERGY

U

SE

4.4

P

ROVISIONS FOR

E

NERGY

M

ANAGEMENT

E

U

9 M

ETERING AND

M

ONITORING

E

XCLUSIONS

Residential buildings.

O

BJECTIVE

Enable building operators to measure, monitor and develop measures to

improve the performance of the building’s engineering systems,

particularly concerning energy use.

C

REDITS ATTAINABLE

2 for centrally air-conditioned buildings, otherwise 1.

P

REREQUISITES

None.

C

REDIT REQUIREMENT

a) Electrical loads

1 credit for ability to measure and monitor all major electrical loads in the

building.

b) Central HVAC plant

1 additional credit where central chiller plant is provided with adequate

instrumentation to determine operating performance.

A

SSESSMENT

The Owner/Operator shall provide details of the measuring and

monitoring equipment installed and records of consumption, in order to

demonstrate that electricity use in the building can be adequately

monitored for audit purposes.

a) Electrical loads

Metering provision shall identify the electricity use pattern for each major

system, fed from the Landlord’s main switchboard(s), i.e., landlords

lighting and small power, transportation, plumbing & drainage systems,

major air handling equipment, such as centralised air handling units for

floors/zones, large designated areas, etc.

Electricity metering (for input power, energy and maximum demand),

together with associated measuring transducers/transformers for

indicating power and energy, shall comply with an appropriate standard

such as BS EN [ 1 ] and to at least accuracy class 1. Sensors for

temperature, flow rate and pressure measurements shall meet the

minimum accuracy requirements in ASHRAE Standard 114 [2] or similar

equivalent.

b) Central HVAC plant

Monitoring of central chiller plant will be assessed on the basis of BSRIA

Technical Note TN 7/94 [ 3 ] or similar specification published by an

appropriate authority. The monitoring system shall allow the overall

performance of the plant and individual chillers to be determined for all

operating modes and range of operating conditions.

B

ACKGROUND

Surveys of a large number of buildings in Hong Kong [4] revealed that

buildings are in general insufficiently equipped with measuring and

monitoring devices for measurement of energy performance. This makes

it particularly difficult to improve the energy efficiency of buildings and

major plant, such as the central chiller plant.

1

British Standard BS EN 60521:1995. Class 0.5, 1 and 2 alternating-current watthour meters.

2

ASHRAE. Standard 114-1986: Energy Management Control Systems Instrumentation, American Society of Heating,

Refrigerating and Air-conditioning Engineers, Inc., USA. 1987.

3

K Calder. The Building Services Research and Information Association. Practical Chiller System Monitoring. Technical

Note TN 7/94. 1994.

4

Yik F W H, Chiu T W. Measuring instruments in chiller plants and uncertainties in performance evaluation. Transactions,

The Hong Kong Institution of Engineers, 5(3) 95-99.
